# HomeAgent
> **中文**: [README.md](./README.md)
The first Agent framework to propose **separation of core domain and application domain**. The kernel performs zero IO — all external interaction is handled by plugins: WebUI, QQ, CLI, file operations, web search, memos — everything is a plugin, the kernel doesn't touch any IO.
Combined with a **three-layer memory architecture** (Context → Document → Graph), it achieves stable long-running single-conversation operation without memory decay.
```go
homed (kernel, zero IO) ← PluginSDK → plugins (all IO capabilities)
```
## Key Innovations
**Separation of Core Domain and Application Domain** — The kernel only handles LLM orchestration, memory management, and knowledge retrieval; all IO capabilities (sending/receiving messages, reading/writing files, network requests, hardware interaction) are implemented by plugins. Plugins can be hot-loaded, independently developed, and independently released. This is not a microservice split of an RPC framework, but a domain-level separation in Agent framework design.
**Three-Layer Memory Architecture** — Solves the memory decay problem for long-running agents:
- **Context Layer**: Pretrained word embedding / TF-IDF fallback relevance-scored event window, protects last 10 entries, maintains topK context entries
- **Document Layer**: Temporary memory with automatic cold data sinking, also supports user-initiated submissions
- **Graph Layer**: SQLite graph database, persists entity relationships and semantic memory, supports distillation pipelines to extract triples from conversations
## Architecture Diagrams
### 1. Message Processing Sequence
```mermaid
sequenceDiagram
participant U as User/Plugin
participant IO as IOManager
participant EV as eventLoop
participant CTX as RelevanceContext
participant LLM as LLM+Tool Loop
participant ST as StageHost
participant MEM as Three-Layer Memory
U->>IO: InjectInput(type, payload)
IO->>EV: inputCh
rect lavender
Note over EV: processTextInput
EV->>ST: StageOnInput Plugin can rewrite/short-circuit
EV->>CTX: Prune(input,topK) StaticEmbedder/TF-IDF cosine pruning
CTX->>MEM: Low-score events archived to Document (original timestamp)
EV->>CTX: Append(input) CleanTemplateText→three-branch vector→5s write
end
rect lightgreen
Note over EV,LLM: process()
EV->>MEM: buildMemoryContext Indexer recalls from Graph (vector+jieba→BFS depth=2)
EV->>MEM: buildSystemPrompt DocQuery summary+Graph memory index+Persona+Skills
EV->>ST: StagePreAction Plugin can pre-intercept
loop Tool loop
LLM->>LLM: drainInterrupts
LLM->>LLM: LLM Chat
LLM->>ST: StagePostAction Plugin can modify/short-circuit
alt No tool call
LLM-->>EV: Returns response
else
loop Each tool
ST->>ST: StageBeforeToolcall Plugin can reject
LLM->>LLM: executeToolCall
ST->>ST: StageAfterToolcall
end
end
end
end
rect lightpink
Note over EV: emitResponse
CTX->>CTX: Append(response)
ST->>ST: StageBeforeOutput Plugin can rewrite
EV-->>U: ResponseCh CLI sync
EV-->>EV: Event bus WebUI SSE
ST->>ST: StageAfterOutput Read-only
EV->>MEM: emitMemoryCandidate
end
```
### 2. Stage Pipeline
```mermaid
flowchart LR
S1[① on_input] --> S2[② pre_action]
S2 --> S3[③ post_action]
S3 --> Q{Has tool?}
Q -->|Yes| S4[④ before_toolcall]
S4 --> T[executeToolCall]
T --> S5[⑤ after_toolcall]
S5 --> S3
Q -->|No| S6[⑥ before_output]
S6 --> S7[⑦ after_output]
style S1 fill:#e1f5fe
style S3 fill:#fff3e0
style S6 fill:#e8f5e9
```
### 3. Three-Layer Memory
```mermaid
flowchart TB
subgraph C[① Context Working Window]
RC[RelevanceContext]
A[Append] -->|CleanTemplateText→three-branch vector| RC
P[Prune StaticEmbedder/TF-IDF Cosine] -->|Low score original timestamp| D
P -->|Keep| TL[timeline→chronological→system prompt]
end
subgraph D[② Document File Memory]
DS[DocStore JSON+TF-IDF]
Q1[Query summary auto-inject] -->|[Related Memory Docs]| SP
Q2[doc_query LLM active recall] -->|Consume+delete source| DS
Q2 -->|Original timestamp write to context| RC
CD[FindColdDocs 72h] -->|docToTriples| G
end
subgraph G[③ Graph Database]
DB[(SQLite)]
IDX[Indexer vector+jieba→BFS depth=2] -->|[Memory Index]| SP
MEM[memory_recall/commit/merge/purge/edit]
SOC[person_query/set_trait]
end
subgraph H[④ Heartbeat Distillation]
REORG -->|Step3 Cold docs| CD
REORG -->|Step4 Bigram Jaccard| CONS[consolidation]
PIPE[Pipeline regex] -->|Name/Address/Likes/Age/Job| DB
end
SP[System Prompt] -->|Sequential assembly| LLM
LLM[LLM] -->|doc_query| Q2
LLM -->|memory_recall| MEM
```
See [`docs/en/ARCHITECTURE.md`](docs/en/ARCHITECTURE.md) for details.
## Web Mascot
Xiaozhai — HomeAgent Web Mascot
